FANUC i-Cell Operators manual Page 237

Operators manual

Page of 739

/ 739

B-75074EN/04 SETTING 5.CIMPLICITY VIEWER

- 211 -

NOTE

A shared drive with the same name is required on the server and

viewer PCs.

When specifying R: for the drive for sharing the i CELL installation

directory on the server PC, set a drive named R: on the viewer PC.

Before setting a drive on the server PC, therefore, check that a

drive with the same name is available on the viewer PC.

(2) When the NC program root directory is not in the i CELL installation
