B-75074EN/04 OPERATION 8.NC DISPLAY AND OPERATION

- 333 -

8.1 OUTLINE

With the NC display and operation function, operations such as NC

state display and parameter setting can be performed for each NC.

The following NC state indications can be provided with this function:

1. CNC status

2. O number, program number, and file name display

3. Actual position display

4. Actual speed display

5. Modal information display

6. Program check display

7. Diagnosis screen display

The following NC operation can be performed:

1. NC parameter setting

NOTE

1 For actual speed display with the M series, the

threading/synchronous feed option and a position

coder are required. If this option is not specified, a

value calculated from the spindle motor speed

instead of a feedback value from the position coder

can be displayed by setting bit 0 of parameter No.

3118 to 1.

2 The FOCAS2/Ethernet function is required.
