C.EXAMPLES OF NC OPERATIONS APPENDIX B-75074EN/04

- 538 -

Examples of operations of FANUC Series 15

Downloading an NC program (NC program number)

The NC program to be downloaded is determined by the NC program

number.

1 Bring the NC into the EDIT mode.

2 Press soft key [PROGRAM] to select the program (memory)

screen.

3 Press soft key [

] twice.

4 Press soft key [READ].

5 Enter “,O????”, where O???? is the NC program number

of the

NC program to be transferred.

To enter the comma (,), press the # key while holding down the

Shift key.

6 Press soft key [EXEC].

Uploading an NC program (NC program number)

When the NC program is saved, the NC program number is used as a

key.

1 Bring the NC into the EDIT mode.

2 Press soft key [PROGRAM] to select the program (memory)

screen.

3 Press soft key [

] twice.

4 Press soft key [PUNCH].

5 Enter ",O????", where O???? is the NC program number of the NC

program to be uploaded.

To enter the comma (,), press the # key while holding down the

Shift key.

This NC program number

is used as a key for simultaneous

storage.

6 Press soft key [EXEC].
