FANUC i-Cell Operators manual Page 728

Operators manual

Page of 739

/ 739

87/98

SHEET

DESCRIPTION

DESIGN

DATE

EDIT

FANUC LTD.

DRAW.NO.

Matsukura

Newl

istered

TITLE:

FANUC CIMPLICITY i CELL

OPERATOR’S MANUAL

05.05.19

B-75074EN/04-2

Making entries in the Point Name Rule Setting dialog box

Enter the setting for each item as described below:

(1) To enter the setting for each of the items A, C, and D under [Rule for

data communication point name], use the mouse or the tab key to select

the desired gravity area and enter a character string.

(2) In cells in table format, enter settings as described below:

 Select the desired cell, using the mouse or the cursor and tab keys

as appropriate.

 After the cell is selected, pressing <ENTER> or <Space> bar allows

an input operation to be started at the end of the existing character

string.

 After the cell is selected, entering an alphanumeric character causes

the existing character string to be deleted, allowing an input

operation to be started with the first character entered.

 After the cell is selected, pressing the <BackSpace> key causes the

existing character string to be deleted, allowing an input operation.

 Pressing the <Esc> key during an input operation causes the cell to

return to the state before input.

 Upon completion of an input operation, perform one of the

following:

- Press <ENTER>

- Move from the cell using the up or down cursor key

- Click another location with the mouse

(3) Click the <Save> button, and the point name rules will be saved.

(4) Click the <Cancel> button to cancel the entries.
