C.EXAMPLES OF NC OPERATIONS APPENDIX B-75074EN/04

- 536 -

C.1 DNC2

Examples of operations of FANUC Series 16/18

Downloading an NC program (NC program number)

The NC program to be downloaded is determined by the NC program

number.

1 Bring the NC into the EDIT mode.

2 Press function key <PROG>.

3 Press soft key [(OPRT)].

4 Press soft key [+].

5 Press soft key [READ].

6 Enter the NC program number

"O????".

7 Press soft key [EXEC].

Uploading an NC program (NC program number)

When the NC program is saved, the NC program number is used as a

key.

1 Bring the NC into the EDIT mode.

2 Press function key <PROG>.

3 Press soft key [(OPRT)].

4 Press soft key [+].

5 Press soft key [PUNCH].

6 Enter the NC program number "O????".

This NC program number

is used as a key for simultaneous

storage.

7 Press soft key [EXEC].
