If a point has been created as described in Subsection 6.3.2.1, "Creating

target projects", click <OK>. If there is no point, create a dummy virtual

point, then click <OK>. The dummy virtual point may have any name

and class.

<5> The Configuration dialog box appears.

<6> From the [Project] menu, click [Machine count configuration], and

For an explanation of how to register an order passwords, refer to Section

2.3, "MACHINE COUNT CONFIGURATION", in Part III, "SETTING",

in the i

CELL Operator's Manual.
