B-75074EN/04 APPENDIX B.NC SETTING

- 507 -

B.4 SETTING THE FOCAS2/Ethernet OF THE OPTION BOARD

FOR Series 30i/31i/32i-A

This section describes the items required to be set to operate the

FOCAS2/Ethernet functions available on the option board for Series

30i/31i/32i-A.

Refer to Section B.5, "SETTING THE EMBEDDED Ethernet FOR

Series 30i/31i/32i-A," in Appendix for the embedded Ethernet function.

B.4.1 Precautions to be Observed when using the FOCAS2/Ethernet

Functions for the First Time

CAUTION

When the FAST Ethernet is used for the first time,

consult with your company’s network administrator

to determine the IP addresses and other settings.

Then, conduct a communications test.

If incorrect IP addresses and other settings are set,

communications may be interfered with or the entire

network might be adversely affected.

Particularly, if a duplicate IP address is set,

communication errors are caused intermittently.

This may result in a CNC's system error.

NOTE

1 One of the following option functions is needed

when the FOCAS2/Ethernet functions are used:

Refer to Item "Ethernet boards or Data Server

boards and CNC options," in Section 3.1 of Part I for

details.

2 There is a limit on the number of FOCAS2/Ethernet

clients connectable to one CNC using the

FOCAS2/Ethernet functions.

Refer to Note 2 in Item “Usable CNCs (When the

FOCAS2/Ethernet is used)” in Section 3.1 of Part I

for details.
