5.CIMPLICITY VIEWER SETTING B-75074EN/04

- 224 -

(4) Select the NC program root directory.

Click the <2> button and select the NC program root directory

from the directory list.

The NC program root directory must be the parent directory of the

default directory of each machine that is set on the i CELL

Configuration dialog box.

Example) When the following directories are set on the i CELL

Configuration dialog box

Machine 1 → C:\Program Files\Fanuc\NcData\01

Machine 2 → C:\Program Files\Fanuc\NcData\02

Set C:\Program Files\Fanuc\NcData as the NC program

root directory.

When the selected NC program root directory is in the i CELL

installation directory, step (5) is not required.

NOTE

To change an NC program default directory, use the

following procedure:

<1> On i CELL CIMPLICITY VIEWER SETUP,

cancel the CIMPLICITY viewer settings for

the server and viewer PCs.

<2> On the i CELL Configuration dialog box,

change the default directory.

<3> On i CELL CIMPLICITY VIEWER SETUP,

make the CIMPLICITY viewer settings for the

server and viewer PCs again.

(5) Select the drive for the NC program root directory.

Use the [Drive] combo box (<3>) to select the drive to be used for

the "NC program root directory."

(6) Click the [Set] button (<4>) to make what you specified effective.

The settings that are made once are effective until they are

canceled.

Restart the server PC and log in. The items related to sharing are

set again based on the settings.

(7) Check that the drives can be shared.

- For Windows NT

Activate Explorer and execute [Map Network Drive] from the

[Tools] menu. The server PC name is displayed in the [Shared

Directories] tree. Click the server PC name.

- For Windows 2000 or Windows XP

Activate Explorer, execute [Map Network Drive] from the [Tools]

menu, and click the <Browse> button. A list of work groups is

displayed. Expand the work group to which the server and viewer

PCs belong, then the server PC.
