B-75074EN/04 OPERATION 9.NC MAINTENANCE

- 345 -

9.1 OUTLINE

With the NC maintenance function, operations such as input/output of

NC maintenance information and various data items can be performed

for each NC.

With the NC maintenance function, the following capabilities are

available:

1. Alarm history display and external operator message history

display

2. Operation history display and history signal setting

3. Various data backup/restoration

4. FROM backup/restoration, SRAM backup

5. Display of history data automatically backed up

NOTE

1 The FOCAS2/Ethernet function is required.

2 When the i CELL is used on the CIMPLICITY viewer,

history data automatically backed up cannot be

displayed.

3 With Series 30i/31i/32i, only various data

backup/restoration can be performed. The other

functions are under development.
