B-75074EN/04 USER CUSTOMIZE 2.ADDING SCREENS

- 401 -

2.5 iCELL_ErrorMessage

iCELL_ErrorMessage is the OLE automation module (Active X DLL)

used to write an error log related to the i CELL to the log file.

iCELL_ErrorMessage is installed in iCELL_ErrorMessage.DLL.

Use this module when writing a user-specific error log.

2.5.1 ErrorMessage

An error log is written to the log file.

This class is installed in iCELL_ErrorMessage.ErrorMessage within

iCELL_ErrorMessage.DLL.

2.5.1.1 Method

Initialize

Performs initialization processing.

- Syntax

object.Initialize LogName

- Setting

LogName

By using a character string expression, set the log identifier of

the log file to which an error log is to be written.

Set “iCELLErrLog”.

- Return value

A Boolean value is returned. When the processing is successful, True is

returned. When the processing fails, False is returned.

Terminate

Performs termination processing.

- Syntax

object.Terminate

- Return value

None

WriteLog

Writes an error log to the log file.

- Syntax

object.WriteLog Message

- Setting

Message

Set a character string expression to be written to the log file.

- Return value

None
