5.OPERATION MONITOR GENERAL B-75074EN/04

- 44 -

5 OPERATION MONITOR

The operation monitor function monitors the operating status of the

machine and collects machining results. The operation monitor function

has the screens described below.

Operation result screen

A power-on time, operating time, cutting time, and machined parts

count are read periodically from the NC, and are summarized monthly

for display.

NOTE

1 The NC must have the operating time and parts

count display option selected.

2 The FOCAS2/Ethernet or DNC2 function is

required. The DNC2 function, however, cannot be

used with Series 0.

Workpiece machining result screen

Data such as the machined parts count and machining end state of each

workpiece is summarized and displayed. A macro program for writing

machining information for each workpiece into the custom macro area

needs to be inserted into the NC program.

NOTE

1 The NC must have the custom macro B option

selected.

2 If the custom macro common area does not have a

free space, the custom macro variable addition

option is required.

3 The FOCAS2/Ethernet function is required.

Tool life management screen

This screen is the same as the tool life screen of the NC.

NOTE

1 The NC must have the tool life management option

selected. With Series 0i-MODEL B/C, the tool life

management function can be used by setting bit 0 of

parameter No. 8132 to 1.

2 There are not the tool life management function and

option for that in Power Mate i.

3 The FOCAS2/Ethernet function is required.

4 This function for Series 30i /31i /32i is under

development.
