B-75074EN/04 OPERATION 9.NC MAINTENANCE

- 355 -

9.5 VARIOUS DATA BACKUP/RESTORATION

With the various data backup/restoration function, the following data

can be backed up/restored:

(1) NC parameters

(2) Tool offset data

(3) Pitch error compensation data

(4) Custom macro variables (in the five hundred)

(5) Workpiece origin offset

NOTE

For pitch error compensation data, the pitch error

compensation function (option) is required. For

custom macro variables, custom macro B (option) is

required. For workpiece origin offset data, the

workpiece coordinate system setting function

(option) is required.

<1> Data backup/restoration
