B-75074EN/04 APPENDIX B.NC SETTING

- 505 -

Display items and setting items

Display items related to the Ethernet functions

The items related to the Ethernet functions are displayed.

Item Description

MAC ADDRESS MAC address of the Data Server board or FAST Data Server

NUMBER OF

SCREENS

Total number of Ethernet error message screens used by the

Ethernet functions

MAXIMUM PATH Number of control systems in the CNC

HDD EXISTENCE Data Server board

Indicates whether a hard disk or ATA flash card is

mounted.

1: Hard disk

2: ATA flash card

FAST Data Server

Indicates whether an ATA flash card is mounted.

0: Not mounted.

2: Mounted.

TCP/IP setting items for the CNC

Set the TCP/IP items for the CNC.

Item Description

IP ADDRESS Specifies the IP address of the CNC.

(Format: "192.168.0.1")

SUBNET MASK Specifies the mask address of the network IP address.

(Format: "255.255.255.0")

ROUTER IP

ADDRESS

Specifies the router IP address.

Specify this address when there is a router on the network.

(Format: "192.168.0.99")

Setting items for connected host 1, host 2, and host 3

Set the items related to the host computer on which the FTP server runs.

Item Description

PORT NUMBER Specifies the port No. to be used by the data server

functions.

Usually, set 21 because the FTP service is used.

IP ADDRESS Specifies the IP address of the host computer.

(Format: "192.168.0.101")

USERNAME Specifies the name of the user to log on to the host computer

using FTP.

(A user name of up to 31 characters can be specified.)

PASSWORD Specifies the password for the above user name.

The password must always be specified.

(A password of up to 31 characters can be specified.)

data server functions are to log in.

(A name of up to 127 characters can be specified.)

NOTE

When the "TCP/IP setting items for the CNC" have

been changed, the power must be turned off then on

again.
