B-75074EN/04 APPENDIX C.EXAMPLES OF NC OPERATIONS

- 537 -

Performing DNC operation of an NC program (NC program number)

When the NC program to be transferred is determined, the NC program

number is used as a key.

1 Bring the NC into the MDI mode.

2 Press function key <SYSTEM>.

3 Press soft key [+] twice.

4 Press soft key [C-OPER]. A screen appears as shown below.

5 Press soft key [(OPRT)].

6 Press soft key [STRING].

7 Enter “O????.PRG”, where O???? is the NC program number

the NC program to be transferred.

8 Press soft key [INPUT].

9 Press soft key [STRING].

10 Bring the NC into the MEM mode.

11 Turn on the DNCI signal from PMC to bring the NC into the RMT

mode.

12 When the cycle start is activated on the NC side, the automatic

operation starts.

[COMMUNICATION OPERATION]

[DNC FILE SELECTION]

MDI **** **** **** ****
