E.DETAILS OF CIMPLICITY POINTS APPENDIX B-75074EN/04

- 564 -

E.2 LIST OF POINTS

E.2.1 Machine-Specific Points

The following table summarizes machine-specific points. The meaning

of each column header of the following table is as follows:

Point name

Indicates the name of a CIMPLICITY point. The first part

"FNCxxxy." of the point name is left out; only the identifier

is indicated.

Data type

Indicates the type of CIMPLICITY point data.

Reading

interval

Indicates the interval at which the point value is updated.

Characters E and D indicate the communication protocol to

which a point is applied.

E : FOCAS2/Ethernet

D : DNC2

i CELL

function

Indicates the i CELL function for which the point is used.

Value and

meaning

Indicates the value that the point can take and the meaning

of the value.

Each value of the item "i CELL function" corresponds to the function

name for a check box displayed on the Function tab of the i CELL

machine screen. (To open the i CELL machine screen, select i CELL

and Machine from the tree in the i CELL configuration screen, and

double-click a desired machine in the grid.) For example, if you turn on

the overview function in the i CELL configuration screen, the point that

has the i CELL function value "Overview" in the following table is

added to CIMPLICITY. If you turn off the function, the related points

are deleted from CIMPLICITY.

Clicking the Disable All button in the i CELL machine screen deletes

all points related to the machine of interest from CIMPLICITY.

The NC connection function reads values from the NC regularly, and

writes them to CIMPLICITY points. The item "Reading interval" in the

table indicates the interval at which the values are read. If the value of a

CIMPLICITY point is changed, the NC connection function writes the

new value to the NC immediately.

NOTE

As the PMC address used for a point, the PMC

address for the first path of an NC is indicated.

When a multipath NC is connected, the PMC

address for each path is used.
