9.NC MAINTENANCE OPERATION B-75074EN/04

- 362 -

9.6.3 SRAM Data Backup

SRAM data can be backed up using the procedure below.

<1> Click the [BackUp NC->PC] button.

<2> From the data type combo box, select SRAM.

<3> From the board name combo box, select the name of the board

where the SRAM to be backed up is installed.

<4> Specify the name of a folder where SRAM data to be backed up is

to be saved.

<5> From the list, select SRAM data to be backed up.

<6> Click the [Exec.] button to start backup operation.

During backup operation, the progress bar indicates the progress

status of backup operation.

* To cancel backup operation, click the [Cancel] button.

* Naming of a backed up SRAM file

To a backed up SRAM file, a name that can be recognized by the

NC boot function is automatically assigned.

NOTE

Before SRAM data can be backed up, the NC must

be placed in the "emergency stop" state.

9.6.4 File List Refreshing

Click the [List Refresh] button to update the list to the latest state.
