B-75074EN/04 USER CUSTOMIZE 2.ADDING SCREENS

- 421 -

2.7.3 Method

Machine selection control: Method installation list

No Method Function

1 Hide Hides the control.

2 Initialize Initializes the control.

3 ReadSlectMcnInfo

Acquires the machine number and path set in the ini file and displays such information on

the control.

4 Refresh Performs forced update operation.

5 Save Saves the selected machine number and path number.

6 Terminate Terminates the processing of the control.

Hide

Hides the control.

- Syntax

object.Hide

- Return value

None

Initialize

Performs initialization processing.

- Syntax

object.Initialize Path

- Setting

Path

Set the %iCELL%\CimProject\ directory by using a

character string expression. It is assumed that under this

directory, a directory storing the ini file under the fanuc

directory is configured.

- Explanation

When this method has been executed successfully, the properties

starting with ComDef… are enabled.

- Return value

A Boolean value is returned. When the processing is successful, True is

returned. When the processing fails, False is returned. When the

processing fails, the cause is set in the property ErrorMessage.

ReadSlectMcnInfo

Acquires the machine number and path set in the ini file then displays

such information, and sets various information items in properties.

- Syntax

object.ReadSlectMcnInfo PCName, FileName, McnNoInScr
