FANUC i-Cell Operators manual Page 142

Operators manual

Page of 739

/ 739

2.BASIC FUNCTIONS SETTING B-75074EN/04

- 116 -

If you register an order password for the i CELL main package and that

for the 10-CNC connection function, for example, you can connect up

to 15 machines, up to ten of which are connected using DNC2 or

Reader/Puncher.

Number of machines connected

using DNC2 or Reader/Puncher : 0 0 10

Maximum machine count : 0 5 15

of the

CELL main package.

(Five machines can be

connected using

FOCAS1/Ethernet.

)

the 10-CNC connection function.

(Ten machines can be

connected using

FOCAS1/Ethernet, DNC2, and

Reader/Puncher.

)

NOTE

Even when only up to five machines are to be

connected, if one of them is to be connected using

DNC2 or Reader/Puncher, you must purchase the

5-CNC connection function option in addition to the i

CELL main package.

The order password is 24 alphanumeric characters. Its term of validity

is limited.

NOTE

It is impossible to register the password with i CELL

after the term of validity.

The order password can be registered only once. It is impossible to

It is also impossible to register one order password with i CELL on

different PCs more than once.

When you connect up to five machines using FOCAS2/Ethernet only

with the i CELL main package, you also need to register the order

password for the i CELL main package.

The Machine Count Configuration dialog box is used to register the

order password. This dialog box is displayed by selecting Project from

the menu bar, then Machine Count Configuration from the Project

menu.
