FANUC i-Cell Operators manual Page 118

Operators manual

Page of 739

/ 739

3.INSTALLATION INSTALLATION B-75074EN/04

- 92 -

3.1 INSTALLATION

i CELL is installed by executing a setup program from CD-ROM.

NOTE

1 The user who install i CELL must have the

"administrator privilege".

2 Before starting the installation procedure, stop all

application programs.

3 The message "UDP Number for C4 Service"

appears during installation. The displayed

information must match the setting in the NC. Take

note of this information.

When you forgot to take note of this information,

see "UDP number for C4 service" described in

Section 3.2, "INFORMATION TO BE

AUTOMATICALLY SAVED TO THE TCP/IP

SERVICE FILE".

The setup procedure follows:

1. Start the computer, and insert the installation CD-ROM into the

drive.

The installer's start window appears automatically.

Click the [Next] button.
