2.PREPARATION INSTALLATION B-75074EN/04

- 90 -

2.3.8 Installing the CIMPLICITY (Basic Function) for Windows NT

Before installing i CELL, install CIMPLICITY.

See Appendix A, "HOW TO INSTALL AND REGISTER

CIMPLICITY," for explanations about how to install CIMPLICITY.

NOTE

1 The user who makes the setting described in this

section must have the "administrator privilege".

2 If you changes the computer name after installing

CIMPLICITY, you need to reinstall CIMPLICITY.

Determine the computer name before installation.

i CELL can operate on the following CIMPLICITY versions:

CIMPLICITY HMI Plant Edition Version 6.1 (English or Japanese

version)

The Japanese version of i CELL comes with the CIMPLICITY system,

but the English version of i CELL does not.

2.3.9 Installing the CIMPLICITY Service Pack (Basic Function) for

Windows NT

After installing CIMPLICITY, install CIMPLICITY Service Pack 2.

Execute the following file on the installation CD:

\Hmi6.1Sp2\setup.bat
