5.5.8.4 Error message storage point

This is the point for storing an error message if an error occurs in CNC

Connection. An error message storage point is required for each CNC.

Data Type

STRING

Elements

256

Initial Value

None

Point Name

FNCxxx01.F_NCC_ERROR (where xxx is a

machine number)

Detail

A value is set by CNC Connection.

If an error occurs, an error message is set at this

point. The same message is also recorded in

the error log.

5.5.8.5 Power status monitor point

This is the point for monitoring the power ON/OFF status of the CNC to

which i

CELL or CNC Communication Mode is connected. A power status

monitor point is required for each CNC.

Data Type

BOOL

Elements

Initial Value

None

Point Name

FNCxxx01.F_PWR (where xxx is a machine

number)

Detail

A value is set by CNC Connection.

The value becomes True if the CNC power

status is ON and False if OFF.
