6.1.2 Comparison between i CELL and CNC Communication Mode

The differences between i

CELL and CNC Communication Mode are as

given in the table below.

Comparison item

CELL

CNC Communication Mode

Contents of the

CIMPLICITY project to

be installed

The various functions of i

CELL are

installed (such as program

management, CNC display and

operation, operation result

management, and maintenance).

Applications must be created by the

user.

Point creation method The points for use with the various

functions of i

CELL are automatically

created during machine setting.

Those points that are required by the

user must be created using Point

Customization.

Those points that are required by user

applications must be created using

Point Customization.

Number of CNCs that can

be connected during

installation

5 5

Maximum number of

CNCs that can be

connected using CNC

connection options

20 75

Method of

communication with the

CNC

FOCAS2/Ethernet,

RS-232-C (DNC2, reader/puncher)

FOCAS2/Ethernet

Drawing numbers of

available CNC connection

options

NOTE

Hatched drawing numbers

are for CNC

Communication Mode

only.

They cannot be used with

CELL.

A08B-9510-J940 5

A08B-9510-J941 10

A08B-9510-J942 15

A08B-9510-J940 5

A08B-9510-J941 10

A08B-9510-J942 15

A08B-9510-J943 20 NOTE

A08B-9510-J944 30

A08B-9510-J945 40

A08B-9510-J946 50

A08B-9510-J947 60

A08B-9510-J948 70
