B-75074EN/04 GENERAL 5.OPERATION MONITOR

- 45 -

5.1 OPERATION RESULT SCREEN

Data created by the operating time and parts count display option of the

NC is read periodically and is summarized monthly for display.

5.1.1 Creating Operation Results

The following data created by the operating time and parts count

display option of the NC is used:

• Power-on time [minutes]

Cumulative power-on time of the NC.

With Series 30i /31i /32i, Series 16/18/21i, PowerMate i, and

Series 0i, the value of parameter No. 6750 is used.

• Operating time [seconds]

Cumulative automatic operating time of the NC.

With Series 30i /31i /32i, Series 16/18/21i, PowerMate i, and

Series 0i, the value of parameter No. 6751 added to the value of

parameter No. 6752 is used.

• Cutting time [seconds]

Cumulative time for cutting feed such as linear interpolation

(G01) and circular interpolation (G02, G03).

With Series 30i /31i /32i, Series 16/18/21i, PowerMate i, and

Series 0i, the value of parameter No. 6753 added to the value of

parameter No. 6754 is used.

• Machined parts count [quantity]

Cumulative number of machined parts counted by M02 and M30.

With Series 30i /31i /32i, Series 16/18/21i, PowerMate i, and

Series 0i, the value of parameter No. 6712 is used.

These data items are read every 30 seconds. Read data is registered in

the database every day.

When the operation result screen is activated, and a month for display is

specified, the collected data of the specified month is read from the

database for display.

NOTE

1 The NC must have the operating time and parts

count display option selected.

2 The FOCAS2/Ethernet or DNC2 function is

required. The DNC2 function, however, cannot be

used with Series 0.
