B-75074EN/04 USER CUSTOMIZE 4.REFERENCING THE DATABASE

- 455 -

4.4.2 Description of VBA Scripts

To reference the database, various procedures described with VBA

scripts of Excel are used.

The major procedures are described below.

In the descriptions below, the name of a procedure and the name of the

module including the procedure are indicated in the following format:

Example GetLastStateConfig :: DB_Common

Procedure name

:: Module name

4.4.2.1 Database operation procedures

DB_Common module

The DB_Common module defines common procedures for acquiring

data from the

i CELL database.

GetLastStateConfig :: DB_Common

This procedure acquires data from the machining end ID setting table.

Data is acquired in an array of the structure (typLastStateConfig).

The following SQL statement is created:

tSQL = "SELECT w.LastID, w.LastStr" & _

" FROM WKPCLastStateConfig w" & _

" WHERE w.Order>= 1 AND w.Order<=5" & _

" ORDER BY w.Order"

From the machining end ID setting table, this SQL statement acquires

LastID and LastStr with Order not less than 1 and not greater than 5 in

ascending order of Order.

CheckMcnConfig :: DB_Common

This procedure checks if a machine name and number passed as

arguments are set in the workpieces process result setting table.

Whether a machine name and number are set is determined from

whether acquired data is present.

The following SQL statement is created:

tSQL = "SELECT wm.McnID, wm.McnName" & _

" FROM WKPCMcnName wm" & _

" WHERE wm.Enable=1 AND wm.McnName='" &

iMcnName & "' AND wm.McnID=" & iMcnNo

From the workpieces process result setting table, this SQL statement

acquires McnID and McnName with Enable set to 1, McnName and

iMcnName matching each other ,and McnID and iMcnNo matching

each other.
