3.OPERATING ENVIRONMENT GENERAL B-75074EN/04

- 10 -

- When the DNC2 is used

An DNC2 is required for the following CNCs:

Series 0-MODEL C, Series 15-MODEL A/B

Series 16-MODEL A/B/C, Series 18-MODEL A/B/C

Series 16i-MODEL A/B, Series 18i-MODEL A/B

Series 21i-MODEL A/B

NOTE

1 The i CELL can be used with one-path control CNC.

The i CELL cannot be used with two-path or

three-path control CNC.

2 DNC2 cannot be used with a CNC that uses the

8-digit O number option.

3 When DNC2 is used, a CNC connection option is

required, which can connect as many CNCs as or

more than the number of CNCs to be connected

using DNC2.

- When the Reader/Puncher is used

Reader/Puncher can be used on the CNC supported the Reader/Puncher

interface.

i CELL can be connected to a CNC using the Reader/Puncher interface

to be used as a replacement of a FANUC CNC program input/output

device as listed below:

FANUC Handy File

FANUC PROGRAM File / FANUC PROGRAM File Mate

FANUC FLOPPY CASSETTE ADAPTER

FANUC FA CARD ADAPTER

NOTE

1 The i CELL can be used with one-path or two-path

control CNC.

The i CELL cannot be used with three-path control

CNC.

2 When Reader/Puncher is used, a CNC connection

option is required, which can connect as many

CNCs as or more than the number of CNCs to be

connected using Reader/Puncher.

3 To display the NC program list of the i CELL on the

NC screen, the floppy cassette directory display

option is required on the NC.
