B-75074EN/04 SETTING 5.CIMPLICITY VIEWER

- 209 -

5.2.2 Allocating Available Drives for Sharing Directories

To use i CELL on the CIMPLICITY viewer, the server and viewer PCs

need to share CIM files, various types of setup files, and NC program

directories.

To share directories, one or two available drives for sharing are required

on the server and viewer PCs.

Before setting items on the i CELL CIMPLICITY VIEWER Setting

Screen, you need to allocate required available drives.

5.2.2.1 Available drive required for sharing the i CELL installation
