"Retry Connection (2)" will be created in "CimVrtlCnc Error Log"

regardless of whether it is a success or a failure. After a

reconnection is successful, this log will not be created.

If a communication error occurs, CNC Connection sets the

communication reconnection instruction point to True, and upon

realizing that the power OFF state of the CNC subsequently, CNC

Connection sets the communication reconnection instruction point

to False.

Enable

Makes a reconnection automatically if a communication error

occurs. If a reconnection cannot be made, a reconnection is

attempted at every specified retry time until it is successful. If

the quality of the communication line is poor, it is possible that an

error recurs immediately after a connection is made. If a

communication error frequently occurs, improve the quality of the

communication line, rather than relying on the reconnection

function. When the function is enabled, use caution because

communication errors may go unnoticed even if they frequently

occur.

If this function causes a reconnection to be attempted, a log called

"Retry Connection (1)" will be created in "CimVrtlCnc Error Log"

regardless of whether it is a success or a failure. After a

reconnection is successful, this log will not be created.

Setting method

For an explanation of setting a reconnection method, refer to Subjection

2.6.2, "Setting up FOCAS2/Ethernet Communication" in Part III,

"SETTING", in the

i CELL Operator's Manual.

For an explanation of setting the retry time to be assumed if a reconnection

is attempted, see "Group 1" in Subsection 5.3.2.2, "Init/Term Scripts Detail

Settings".
