B-75074EN/04 APPENDIX E.DETAILS OF CIMPLICITY POINTS

- 563 -

E.1.2 Point Naming Rules

i CELL uses two types of points. One type (machine-specific point) is

used for individual machines separately, and the other type (i CELL

-common point) is used in common throughout i CELL.

Machine-specific points

The name of each machine-specific point consists of two parts. The first

part identifies the machine and series, and the second part identifies the

type of the point. A period "." is used to separate the parts. The format

of the point name is:

FNCxxxy.<identifier>

where:

FNC is a fixed character string.

xxx is a three-digit machine number. It can range from 001 to 999.

y is a two-digit series number.

Point type y value

- If there is only one NC series, all points for that machine

- If there are two or more NC series, points for series 1

- If there are two or more NC series, points not related to series

If there are two or more NC series, points for series 2 02

<Identifier> identifies a point type.

Example)

The name of a point is "FNC0011.F_AL" if the machine number is

1, the series number is 1, and the identifier is "F_AL" (NC alarm).

i CELL -common points

The i CELL -common points are independent of machines. The name of

each i CELL -common point consists of two parts. The first part is a

fixed character string, and the second part identifies the point name. A

period "." is used to separate the parts. The format of the point name is:

FNCSYSP.<identifier>

where:

FNCSYSP is a fixed character string.

<identifier> identifies a point type.
