4.REFERENCING THE DATABASE USER CUSTOMIZE B-75074EN/04

- 436 -

4.1 OVERVIEW

The following Excel samples for referencing the i CELL database are

available:

Sample 1. Referencing machining result data

As with the Machining Result screen, database information is displayed

as graphs and tables on an Excel sheet. Database information can also

be displayed as CSV data.

File name: RunTimeA.xls

Installation path: %iCELL%\Sample\DataExport\Excel

(%iCELL% is the folder where the

i CELL is installed.)

Sample 2. Referencing workpieces process result data

As with the Workpieces Process Result screen, database information is

displayed on an Excel sheet. However, data is displayed in the CSV

format, and planned count data cannot be input, and no pie chart can be

displayed.

File name: WorkProcA.xls

Installation path: %iCELL%\Sample\DataExport\Excel

4.2 REFERENCING THE ACCESS DATABASE FROM EXCEL

This section describes the method of acquiring data from the Access

database by using a VBA script of Excel and displaying the acquired

data on an Excel sheet.

Specifically, a connection is made to the Access database with ODBC

Direct, then data is acquired using SQL statements through a VBA

script of Excel then is displayed on an Excel sheet. Users who are

familiar with the method need not read this section.

Starting Excel

To display the Excel samples, start Excel by using one of the following

methods:

Method 1

Double-click an Excel sheet to be used.

Method 2

(1) From the menu, select [Start] → [Programs], then select

[Microsoft Excel] to start Excel.

(2) Read an Excel file to be used.

When a dialog box for selecting whether to enable macros appears,

select Enable in either case.

Starting VBEditer

To edit the VBA script of an Excel sample, start VBEditor according to

the procedure below.

From the Excel menu, select [Tool] → [Macro], then select [Visual

Basic Editor] to start VBEditer.
