3.DATABASE SPECIFICATIONS USER CUSTOMIZE B-75074EN/04

- 434 -

3.3.8 WKPCDspLastState - Machining End State Display Table

This table is temporarily used to display machining end state. After the

table is displayed, all data is deleted.

Do not modify the design of the table.

NOTE

Do not modify data when the Workpieces Process

Result screen is displayed. Otherwise, the screen

may not be displayed normally.

Field name Data type Description

ID Auto number AutoNumber

McnID Numeric type Machine ID (1 to 999)

WorkID Numeric type Workpiece ID (0 to 99,999,999)

Onum Numeric type O number (0 to 99,999,999)

PlanNum Numeric type Planned machining count

ProcNum Numeric type Total machining count

LastID0 Numeric type Value obtained by subtracting, from the total machining count, the number of

machining end state IDs set to 0 and the number of machining end state IDs with

the Order field of the machining end ID setting table set to a value from 1 to 5

LastID1 Numeric type Number of machining end state IDs with the Order field of the machining end ID

setting table set to 1

LastID2 Numeric type Number of machining end state IDs with the Order field of the machining end ID

setting table set to 2

LastID3 Numeric type Number of machining end state IDs with the Order field of the machining end ID

setting table set to 3

LastID4 Numeric type Number of machining end state IDs with the Order field of the machining end ID

setting table set to 4

LastID5 Numeric type Number of machining end state IDs with the Order field of the machining end ID

setting table set to 5

NormNum Numeric type Normal end count. Sum of the number of LastID1s and the number of machining

end state IDs set to 0.
